July 2018

ZETTLER DISPLYAS recently launched the ATM0700U6B-T series TFT display modules with UART interface which aims to make customers’ development process simpler.

In the field of industrial control application, many devices communicate via UART. ZETTLER ATM0700U6B-T series display module with UART interface built-in will allow customers to use TFT modules with the low cost MCU. Meanwhile, ZETTLER can provide specialized tools to assist customers to develop the UI interface. These will significantly simplify the customer's development process and make it more intuitive.

Comparing with RGB and LVDS interface display module, UART interface display module offers the advantages of:

1. Built-in images storage chip which can store the UI interface into the module.

2. Built-in Chinese and English fonts which can be directly pull out.

3. Built-in touch screen controller which enables direct access of touch screen coordinates.

(With the provided special tools, touch-jump can be implemented directly, no need of any software code control)

4. Built-in functions such as drawing points, lines, and circles can simplify the client software.

5. Built-in backlight PWM control can directly adjust the backlight brightness by entering orders.

6. Built-in functions of capturing and panning the images.
